Beschreibung
The LHD-8R-EXT-FPS surge protector is a modern device designed to provide comprehensive protection for CCTV systems. With 8 video channels, it is an excellent solution for installations using AHD, HD-CVI, HD-TVI, and Turbo HD standards. Its innovative design and power distribution features make it a reliable tool for any professional monitoring system. The device not only protects against surges but also effectively distributes power to connected cameras, ensuring safety through automatic circuit disconnection in case of dangerous current spikes. Compatible with various transmission standards, it simplifies integration into existing systems.
Eigenschaften
- Marke
- ewimar
- Modell
- lhd-8r-ext-fps
- Gewicht
- 0.3 kg
- EAN
- 5904041750816
- Dimensions
- 482 mm × 115 mm × 42 mm
- Automatic circuit disconnection
- ✓
- Built in fuses
- ✓
- Compatible with
- AHD, HD-CVI, HD-TVI
- Power distribution
- ✓
- Rack mountable
- ✓
- Signal transmission
- bidirectional
- Surge protection
- ✓
- Line to ground
- 90V, 2x10kA @ 8/20µs
- Line to line
- 6V, 15A @ 8/20µs
- Max surge level
- 4kV
- Temperature range
- -40°C to +60°C
